Door operation: Internal
External
Purging:
Pressure gauge:
One
Ø250mm x 400mm long
Cylindrical
Stainless steel (304), thickness 3mm
Satin non glare
Satin non glare
Anodised aluminium, 12mm thick, one hand operation
Vertical lift pivot hinge
Lift off
Manually operated valves
Analogue
Pressure Control:
Full automatic pressure control via pressure switch and gas solenoids
Over/under pressure is maintained by a low maintenance gas bubbler -2000 to +500 Pa (-8 to +2 WG)
Gas Scrubbing System:
Removal of moisture and oxygen using a closed loop re-circulation system
Attainable purity: <1ppm moisture
<1ppm oxygen
Blower: Precision side channel blower
Quiet running
High flow rate
Long life
Oil free
Externally mounted
Regeneration: Off box regeneration system
Window:
Toughened safety glass 10mm
Glove Ports:
Anodised aluminium
Gloves:
8” (204mm diameter)
Individually gas purgeable
Glove change independent of external atmosphere
Switchable positive/negative control
Polycarbonate window
Gas/electrical/signal breakthroughs
316 stainless steel construction
Polycarbonate/acrylic construction
Digital, integrally fitted, range: % or PPM Digital, integrally fitted, range: % or PPM
Edwards (RV5 recommended)
To customer’s specification
Powder coated mild steel (stainless steel option) including fixed feet or castors
